Mã SP: ST.BE.A0013
Giá: Liên hệ
Learn the principles and practice with full-wave, integral,
and differential diode control circuits
• Learn the principles and practice with low-pass, high-pass,and equal-pass filter circuits
• Learn the principles and practice of limiter, latch, and sampling circuits
• Learn the principles, practice with window comparator circuits
• Basic characteristics and parameters of operational amplifiers
• The practice set helps students improve their theoretical
knowledge of power source circuits
• Theory of DC rectifier circuit using controlled half-wave/
full-wave SCR
• SCR trigger circuit by UJT, AC voltage regulator circuit by Triac
• The circuit board has built-in components and intuitive, easy-to-understand circuit diagrams
• Verify the theories you have learned
• Calculate and design basic electronic circuits
• Understand the uses and application scope of each circuit
• Know how to measure, detect errors and fix circuit errors
• Box size: 173x169x25mm (LxWxH)
• Quality Management Standard ISO 9001:2015
• Designed as separate modules with the same connection
standard
• Black aluminum box style, molded plastic lid
• The printing pattern guides the printing of the film on the
module surface, ensuring aesthetics, longevity of the device
• Box size: 173x169x25mm (LxWxH)
• Power supply: ±5VDC, 0 ~ ±15VDC
• Adjustable rheostat: 0 ~ 10KΩ
• Operational amplifier IC power supply ±18V
• Black anodized aluminum case
• Practice circuits divided into clear blocks
• M2 signal jack
• Box size: 173x169x25mm (LxWxH)
• Power supply: 12VAC, 0 ~ ±15VDC
• Adjustable rheostat: 0 ~ 10KΩ
• Operational amplifier IC power supply ±18V
• Black anodized aluminum case
• Practice circuits divided into clear blocks
• M2 signal jack
• Box size: 173x169x25mm (LxWxH)
• Power supply: 0 ~ ±15VDC
• Adjustable rheostat: 0 ~ 10KΩ
• Operational amplifier IC power supply ±16VDC
• Black anodized aluminum case
• Practice circuits divided into clear blocks
• M2 signal jack
