DC Servo Motor Control Training Kit
Product Code: ST.IE.A4302
Price: Contact
The DC Servo Motor Control Training Kit is a comprehensive educational solution designed to help learners master the structure, operating principles, and real-world control of DC servo motors. The kit provides hands-on experience in open-loop and closed-loop speed control, angular position control, driver parameter setup, and PID coefficient calculation. Ideal for training programs in automation, mechatronics, and PID control systems.
- Device information
- Specifications
TRAINING CONTENT
- General introduction to the training kit’s real-world applications and the function of each module
- Survey the power supply for DC servo motors
- Study the hardware and operating principles of DC servo motors
- Learn the PID control principles
- Practice wiring and experimentation using included modules
- Practice open-loop speed control of DC servo motors
- Practice closed-loop speed control of DC servo motors
- Practice angular position control of DC servo motors
- Understand the control principles of DC servo controllers
- Acquire skills to configure driver parameters for specific applications
- Calculate PID coefficients for the control system
- Operate and handle the training equipment confidently
