A Power Source Adjustment Circuit Experiment Kit is an educational tool designed to help users understand the operation and adjustment of power supply circuits, which are critical in providing stable and controlled voltage and current for various electronic applications.
• Identify components in the circuit
• Introducing power supply adjustment
• Parallel, series, pressure feedback, voltage feedback,
current adjustment, 3-pin IC adjustment operations
• Reverse current limiting protection circuit
• DC to DC conversion characteristics and performance
• Basic concepts of troubleshooting and troubleshooting
• The practice set helps students improve their theoretical
knowledge of power source circuits
• Theory of source voltage regulator circuit, source voltage
regulator circuit, current source circuit
• The circuit board has built-in components and intuitive,
easy-to-understand circuit diagrams
• Verify the theories you have learned
• Calculate and design basic electronic circuits
• Understand the uses and application scope of each circuit
• Know how to measure, detect errors and fix circuit errors
• Box size: 173x169x25mm (LxWxH)
• Quality Management Standard ISO 9001:2015
• Designed as separate modules with the same connection
• standard
• Black aluminum box style, molded plastic lid
• The printing pattern guides the printing of the film on the module surface, ensuring aesthetics, longevity of the device
• Box size: 173x169x25mm (LxWxH)
• Power supply: 12VAC, 0 ~ ±15VDC
• Adjustable rheostat: 0 ~ 10KΩ
• Voltage regulator diodes: 3V3, 5V1, 12V
• Black anodized aluminum case
• Practice circuits divided into clear blocks
• M2 signal jack
• Box size: 173x169x25mm (LxWxH)
• Power supply: +5VDC, 0 ~ +15VDC
• IC power source regulator
• Power supply: 2.75V ~ 15V
• Output voltage: 1.25V ~ 13.8V
• Black anodized aluminum case
• Practice circuits divided into clear blocks
• M2 signal jack
• Box size: 173x169x25mm (LxWxH)
• Power supply: 0 ~ ±15VDC
• Adjustable rheostat: 0 ~ 1KΩ, 0 ~ 10KΩ
• Operational amplifier IC:
• Power supply: 3V ~ 32V, ±1.5 ~ 16V
• Offset input voltage: 2~3mV
• Black anodized aluminum case
• Practice circuits divided into clear blocks
• M2 signal jack
