Mã SP: ST.BE.A0007
Giá: Liên hệ
• Recognize, become familiar with and locate components
in the circuit
• Introduction to multistage amplification
• DC/AC operation of common Base, Emitter, Collector circuit
• Temperature effects on fixed polarity, voltage divider circuits
• Use the Transistor parameter table
• DC operation RC coupled amplifier
• DC/AC operation of transformer-coupled, direct-coupled amplifier
• Handling and troubleshooting circuit problems
• The practice set helps students improve their theoretical
knowledge of amplifier circuits using transistors
• Common B amplifier circuit, common E amplifier, common C amplifier, coupling circuits…
• The circuit board has built-in components and intuitive, easy-to-understand circuit diagrams
• Box size: 173x169x25mm (LxWxH)
• Quality Management Standard ISO 9001:2015
• Designed into removable modules that can be assembled
flexibly with the same connection standard
• Black aluminum box style, molded plastic lid
• The printing pattern guides the printing of the film on the module surface, ensuring aesthetics as well as the longevity of the device
• Box size: 173x169x25mm (LxWxH)
• Power supply: 12VAC, 0 ~ ±15VDC
• Adjustable rheostat: 0 ~ 10KΩ, 0 ~250KΩ
• Power resistor: 4.7Ω/5W
• Black anodized aluminum case
• Practice circuits divided into clear blocks
• M2 signal jack
• Box size: 173x169x25mm (LxWxH)
• Power supply: 12VAC, 0 ~ ±15VDC
• Adjustable rheostat: 0 ~ 250KΩ
• Output voltage: symmetrical 6VAC
• Output current: 0.2A
• Black anodized aluminum case
• Practice circuits divided into clear blocks
• M2 signal jack
