Product Code: ST.AT.A0130
Price: Contact
- Manufacture: Tan Phat
I. Training/practice content
- Connect the power cord and signal cord to the FX3U PLC
- Practice programming basic logic commands
- Practice programming commands using a Timer and Counter
- Practice programming comparison and arithmetic commands
- Learn and program the HMI GS2107-WTBD interface
- Programming control and monitoring between PLC and HMI
II. Skills acquired
- Know the hardware structure of the FX3U PLC programmer
- Know how to connect the power supply, digital input and output, and analog input and output of PLC FX3U
- Know how to write programs for PLC FX3U with functions: logic, Timer, Counter, mathematics
- Know how to create interfaces on HMI GS2107-WTBD
- Know how to program controls. Monitoring between HMI and PLC
III. List of devices
- 01 PLC control module
- 01Analog input module
- 01 Analog output module
- 01 Ethernet communication module
- 01Human-Machine interface screen module
IV. Detailed technical specifications
1. FX3U-64MT/ESS PLC CPU module
* Specifications
- CPU block
+ Power supply: 100-220VAC
+ CPU type: FX3U-64MT
+ Number of digital inputs: 32 DI
+ Number of digital outputs: 32 DO (Transistor)
+ Input voltage signal: 24VDC
+ Response time: 0.065 µs
+ Program capacity: 64000 steps
+ Connection type: USB, RS232C, RS485
+ Manufacturer: Mitsubishi
2. Analog input signal module
* Specifications
- Number of analog inputs: 4 AI
- Processing speed: 200ms
- Adjustable voltage signal input: 0 ~ 10VDC
- Adjustable current signal output: 4 ~ 20mADC
- Manufacturer: Mitsubishi
3. Analog output signal module
* Specifications
- Number of analog inputs: 4 AO
- Processing speed: 200ms
- Adjustable voltage signal input: 0 ~ 10VDC
- Adjustable current signal output: 4 ~ 20mADC
- Manufacturer: Mitsubishi
4. Ethernet communication module
* Specifications
- Type: Network module
- Power source: 30mA/DC 5V
- Data transmission speed: 100Mbps or 10Mbps
- Maximum section length: 100m
- Communication mode: Full/Half duplex
- Manufacturer: Mitsubishi
5. Human-machine interface screen module
* Specifications
- Power supply: 24VDC
- Screen type: GS2107-WTBD - Manufacturer Mitsubishi
- Interface type: touch - touch panel
- Screen size: 7"
- Communication support: RS-422/RS-232/USB/Ethernet
- Number of colors: 65536 colors
6. Connection cable for programming
- Computer connection port: USB
- Programming cable: Ethernet
7. Accessory set
- Accessories used for connection practice exercises: M4 safety wires, network cables, power cords
8. Technical documentation set
- User manuals and exercises, including:
+ Instructions for using the device
+ Practical guidance documents
- Standard:
+ Management standards: Modules are designed and assembled according to ISO 9001:2008 Quality Management standards
- Module surface: CT3 powder coated to ensure durability and aesthetics
- Instructional printing style: Printing film on the module surface, ensuring aesthetics as well as longevity of the device.
- IO ports are exposed to DB40s for quick connection.
- Input signals are simulated by logic operations and buttons.
- On the panel surface, EC standard anti-shock 4mm jacks are integrated, creating input and output signals and meters for convenient practice.
- Integrated Human - Machine interface screen
- Integrated communication standards: RS232, RS485, Ethernet
