AVR MICROCONTROLLER IMPLEMENTATION

AVR MICROCONTROLLER IMPLEMENTATION

Product Code: ST.MP.A0010

Price: Contact

Implementing an AVR microcontroller involves using its hardware and software capabilities to create embedded systems or applications.

  • Device information
  • Specifications

TRAINING CONTENT

• Practice learning the structure of 8051, AVR, and PIC microcontrollers.
• Practice learning the instruction set and registers.
• Practice programming I/O communication.
• Practice programming Timer and Counter control.
• Practice programming with external interrupts.
• Practice programming ADC reading and processing.
• Practice programming PWM motor control pulses.
• Practice programming single LED display control.
• Practice programming 7-segment LED display control.
• Practice programming LED matrix display control.
• Practice programming matrix keypad reading.
• Practice programming RS232 standard computer communication.
• Practice programming RS485 standard computer communication.

• CPU ATMEGA128
• Flash memory: 128 Kbytes
• Memory: SRAM 4 Kbytes, EEPROM 4 Kbytes.
• Frequency: Up to 16 MHz
• Function: 04 Timer/Counter, 08 ADC (10bit),
• 02 PWM (8bit),
• Communication: 02 UART, SPI, I2C.
• Number of I/O ports: 53 DIO
