1. Three-Phase Circuit Breaker Training Module – TPAC.B4500

Technical Specifications

• Enclosure dimensions: 300 × 139 × 131 mm (L × W × H)
• Standards:
  • ISO 9001:2015 Quality Management System
  • Compliant with TCVN 5699-1:2010 and IEC 60335-1:2010 standards for power rating, current, leakage current, and dielectric strength
• Three-phase circuit breaker
• Number of protected poles: 3 poles
• Rated current: 25A
• Rated voltage: 400VAC, 50/60Hz

Main Components

• 01 Plastic enclosure
• 01 Module panel
• 01 Three-phase circuit breaker
• 01 Set of M4 sockets

2. AC Power Supply Module – TPAC.A2300

Origin

• Vietnam

Technical Specifications

• Enclosure dimensions: 300 × 272 × 131 mm (L × W × H)
• Standards:
  • ISO 9001:2015 Quality Management System
  • Compliant with TCVN 5699-1:2010 and IEC 60335-1:2010 standards
• Input power supply:
  • Three-phase, 380VAC/50Hz, star connection
• Output power supply:
  • Three-phase 220VAC/50Hz, star connection
  • Three-phase 380VAC/50Hz, star connection
• Transformer capacity: 3KVA
• Integrated phase indicator lamps
• Primary overcurrent protection by fuse

Main Components

• 01 Set of M4 sockets
• 01 Enclosure
• 01 Module panel
• 01 Transformer
• 03 Fuses
• 03 Phase indicator lamps

3. Transformer Training Module – TPAE.L4500

Origin

• Vietnam

Technical Specifications

• Enclosure dimensions: 350 × 210 × 300 mm (L × W × H)
• Standards:
  • ISO 9001:2015 Quality Management System
  • Compliant with TCVN 5699-1:2010 and IEC 60335-1:2010 standards
• Input power supply:
  • Three-phase, 380VAC/50–60Hz, star connection
• Output:
  • Three-phase
• Output voltage levels per phase:
  • 0 ~ 64VAC ~ 95VAC ~ 110VAC ~ 127VAC ~ 220VAC / 50–60Hz
• Transformer capacity: 6KVA
• Integrated phase indicator lamps
• Primary overcurrent protection by fuse

Main Components

• 01 Set of M4 sockets
• 01 Enclosure
• 01 Module panel
• 01 Transformer
• 03 Fuses
• 03 Phase indicator lamps

4. DC Power Supply Module (Symmetrical DC15V) – TPAP.B0100

Origin

• Vietnam

Technical Specifications

• Enclosure dimensions: 300 × 139 × 131 mm (L × W × H)
• Standards:
  • ISO 9001:2015 Quality Management System
  • Compliant with TCVN 5699-1:2010 and IEC 60335-1:2010 standards
• Input power supply: 220V/50Hz
• Output voltage: ±15VDC
• Rated output current: 3A
• Equipped with power indicator lamps and fuse protection against overload and short circuit

Main Components

• 01 Fiberglass panel
• 01 Plastic module enclosure, standard height 300 mm
• 01 Set of M4 sockets
• 01 Power supply circuit
• 02 Switching power supplies
• 01 Fuse
• 01 Illuminated power switch
• 02 Power indicator lamps

5. Reference Voltage Generation Module – TPAP.G0100

Origin

• Vietnam

Technical Specifications

• Enclosure dimensions: 300 × 139 × 131 mm (L × W × H)
• Standards:
  • ISO 9001:2015 Quality Management System
  • Compliant with TCVN 5699-1:2010 and IEC 60335-1:2010 standards
• Power supply: ±15VDC
• Output voltage:
  • 0 ~ +10V or -10 ~ +10V selectable by switch
• Output voltage adjustable via rotary knob
• Output current: 100mA
• Output voltage displayed by 4-digit 7-segment LED
• Resolution: 0.01V

Main Components

• 01 Fiberglass panel
• 01 Plastic enclosure
• 01 Set of M4 sockets
• 01 Potentiometer circuit
• 01 Voltage generation circuit
• 01 Display circuit
• 01 Multi-turn potentiometer
• 01 Logic switch
• 01 Rotary knob

6. Three-Phase Firing Angle Control Module – TPAP.G3000

Origin

• Vietnam

Technical Specifications

• Enclosure dimensions: 300 × 272 × 131 mm (W × L × H)
• Standards:
  • ISO 9001:2015 Quality Management System
  • Compliant with TCVN 5699-1:2010 and IEC 60335-1:2010 standards
• Power supply: ±15VDC
• Synchronization signal:
  • Three-phase, four-wire, 0 ~ 400VAC
• Control angle range:
  • 0 ~ 180°
  • Adjustable minimum and maximum firing angle limits
• Control voltage:
  • 0 ~ 10V
• Control pulse:
  • 15Vp electrically isolated
• Control capability:
  • Up to 6 thyristors
• Control modes:
  • Pulse trigger
  • Pulse train trigger
• Firing angle displayed via 7-segment LED
• Run/stop control by switch

Main Components

• 01 Fiberglass panel
• 01 Plastic enclosure
• 01 Set of M4 sockets
• 01 Potentiometer mounting circuit
• 01 Firing angle control circuit
• 01 Four-digit 7-segment LED display
• 02 Potentiometers
• 02 Rotary knobs
• 03 Transformers

7. Differential Amplifier Module – TPAP.G1000

Origin

• Vietnam

Technical Specifications

• Enclosure dimensions: 300 × 139 × 131 mm (L × W × H)
• Standards:
  • ISO 9001:2015 Quality Management System
  • Compliant with TCVN 5699-1:2010 and IEC 60335-1:2010 standards
• Power supply: 220V/50Hz
• Number of input/output channels: 4
• Input voltage ranges:
  • 0 ~ 10V
  • 0 ~ 100V
  • 0 ~ 500V
• Input range selectable by switch
• Output voltage range:
  • 0 ~ 10V
• Maximum conversion frequency:
  • 100kHz
• Two output connection standards:
  • M4 sockets
  • BNC connector for oscilloscope connection

Main Components

• 01 Fiberglass panel
• 01 Plastic module enclosure
• 01 Set of M4 sockets
• 01 BNC connector
• 01 Power supply circuit
• 01 Amplifier circuit
• 02 Logic switches
• 01 Fuse
• 01 Illuminated power switch
• 01 Transformer

8. Current/Voltage Conversion Module – TPAP.G2000

Origin

• Vietnam

Technical Specifications

• Enclosure dimensions: 300 × 139 × 131 mm (L × W × H)
• Standards:
  • ISO 9001:2015 Quality Management System
  • Compliant with TCVN 5699-1:2010 and IEC 60335-1:2010 standards
• Power supply: 220V/50Hz
• Number of input/output channels: 2
• Input current ranges:
  • 0 ~ 1A
  • 0 ~ 5A
  • 0 ~ 20A
• Input range selectable by switch
• Output voltage range:
  • 0 ~ 10V
• Maximum conversion frequency:
  • 100kHz
• Input overcurrent indication available

Main Components

• 01 Fiberglass panel
• 01 Plastic enclosure
• 01 Set of M4 sockets
• 01 Power supply circuit
• 01 Conversion circuit
• 01 Transformer
• 01 Fuse
• 01 Illuminated power switch

9. Thyristor Training Module – TPAP.C1300

Origin

• Vietnam

Technical Specifications

• Enclosure dimensions: 300 × 272 × 131 mm (L × W × H)
• Standards:
  • ISO 9001:2015 Quality Management System
  • Compliant with TCVN 5699-1:2010 and IEC 60335-1:2010 standards
• Number of thyristors: 6
• Rated voltage: 800V
• Rated current: 20A
• Integrated LC surge protection circuit
• Configurable for:
  • Single-phase and three-phase star rectifier circuits
  • Single-phase and three-phase bridge rectifier circuits with full control
• Can be combined with diodes to form semi-controlled rectifier circuits

Main Components

• 01 Fiberglass panel
• 01 Plastic enclosure
• 01 Set of M4 sockets
• 01 Set of power thyristors
• 01 Set of AC capacitors
• 01 Set of power resistors
• 02 Aluminum heatsinks

10. Fuse Training Module – TPAC.I0100

Origin

• Vietnam

Technical Specifications

• Enclosure dimensions: 300 × 139 × 131 mm (L × W × H)
• Standards:
  • ISO 9001:2015 Quality Management System
  • Compliant with TCVN 5699-1:2010 and IEC 60335-1:2010 standards
• Number of branches: 4
• Rated current: 5A

Main Components

• 01 Fiberglass panel
• 01 Plastic enclosure
• 04 Fuses

11. AC Ammeter Training Module – TPAI.A0200

Origin

• Vietnam

Technical Specifications

• Enclosure dimensions: 300 × 139 × 131 mm (L × W × H)
• Standards:
  • ISO 9001:2015 Quality Management System
  • Compliant with TCVN 5699-1:2010 and IEC 60335-1:2010 standards
• Current measurement range:
  • 0 ~ 10AAC
• Display type:
  • Analog pointer
• Display angle:
  • 90°
• Short-circuit and overload protection

Main Components

• 01 Fiberglass panel
• 01 Plastic enclosure
• 01 Set of M4 sockets
• 01 Fuse
• 01 Analog 10A AC ammeter

12. AC Voltmeter Training Module – TPAI.B0100

Origin

• Vietnam

Technical Specifications

• Enclosure dimensions: 300 × 139 × 131 mm (L × W × H)
• Standards:
  • ISO 9001:2015 Quality Management System
  • Compliant with TCVN 5699-1:2010 and IEC 60335-1:2010 standards
• Voltage measurement range:
  • 0 ~ 500VAC
• Display type:
  • Analog pointer
• Display angle:
  • 90°
• Equipped with volt selector switch for phase voltage measurement

Main Components

• 01 Fiberglass panel
• 01 Plastic enclosure
• 01 Set of M4 sockets
• 01 Volt selector switch
• 01 Analog 500V AC voltmeter

13. Three-Phase Resistive Load Training Module – TPAN.E3000

Technical Specifications

• Standards:
  • ISO 9001:2015 Quality Management System
  • Compliant with TCVN 5699-1:2010 and IEC 60335-1:2010 standards
• Number of branches:
  • 3 load branches for three-phase operation, divided into 6 levels
• Input voltage:
  • Three-phase 380VAC/50Hz
• Resistance value:
  • 100Ω
• Rated power:
  • 1000W
• Integrated cooling fan

14. Inductive Load Training Module – TPAN.E3101

Technical Specifications

• Standards:
  • ISO 9001:2015 Quality Management System
  • Compliant with TCVN 5699-1:2010 and IEC 60335-1:2010 standards
• Number of branches:
  • 3 load branches for three-phase operation, divided into 6 levels
• Rated voltage Y/Δ:
  • 380/220VAC, 50Hz
• Rated current:
  • 0.5 ~ 2A

15. AC Motor Training Module – TPAE.F0300

Origin

• Vietnam

Technical Specifications

• Dimensions: 293 × 180 × 279 mm (L × W × H)
• Standards:
  • ISO 9001:2015 Quality Management System
  • Compliant with TCVN 5699-1:2010 and IEC 60335-1:2010 standards
• Motor type:
  • Three-phase AC motor
• Rated voltage:
  • Y connection: 380VAC/50Hz
  • Δ connection: 220VAC/50Hz
• Rated speed:
  • 1420 rpm
• Housing material:
  • Cast iron
• Power:
  • 0.75kW

Main Components

• 01 Three-phase motor
• 01 Set of M4 sockets
• 01 Coupling

16. Three-Phase Power Meter Training Module – TPAI.C4200

• Origin: Vietnam

Technical Specifications

• Enclosure dimensions: 300 x 272 x 131 mm (L x W x H)
• Standards:
  • ISO 9001:2015 – Quality Management System
  • Compliant with TCVN 5699-1:2010 and IEC 60335-1:2010 standards for power and current ratings, leakage current, and dielectric strength
• Power supply: 3-phase AC
• Power measurement range: 0 ~ 10 kW
• Display type: Analog pointer
• Display angle: 90°
• Current transformer ratio: 20/5

Main Components

• 01 Bakelite panel
• 01 Plastic enclosure
• 01 Set of M4 connectors
• 02 Current transformers
• 01 Analog three-phase power meter

17. Accessories Set

Technical Features

• Safety connection wires, Ø4 mm
• Rated current capacity: 19A
• Sufficient number of connectors for all practical exercises

18. Technical Documentation Set

The documentation includes:

• Equipment user manual
• Practical training manual

19. ETEK-Lab Digitalization, Simulation, and Training Support Software

a. General Features

• Vietnamese interface, user-friendly and easy to operate
• Web-based platform accessible through internet browsers
• Allows access anytime and anywhere using personal accounts
• Supports login with individual usernames and passwords
• User role management for teachers and students
• Supports storage and management of lectures, learning materials, and laboratory documents
• Course contents, lectures, and practical exercises can be continuously updated by users
• Efficient support for theoretical materials and practical content associated with training equipment
• Software data hosted on the supplier’s cloud server
• The software has a Copyright Registration Certificate issued by the Copyright Office

b. Lecture Development Support Functions

• Import lecture content from Word files
• Create lecture content directly on the software platform
• Support insertion of illustrative images
• Support multiple types of multiple-choice questions
• Allows creation of question banks for assessments and examinations
• Lecture content management

c. AI-Integrated Teaching Support Technology

• The software integrates Artificial Intelligence (AI) technology to support teachers in developing training content, preparing lectures, and designing examinations
• AI helps reduce lesson preparation time and supports fast, systematic, and effective development of training materials
• Supports creation of lecture structures based on topics or course content
• Automatically generates key lecture components such as learning objectives, knowledge content, illustrative examples, and discussion questions
• Supports summarization of lengthy documents into key teaching points
• Converts technical documents into learner-friendly educational content
• Assists in editing and improving lectures while adding practical examples and real-life scenarios
• Generates illustrative images and visual diagrams suitable for lesson content
• Automatically creates assessment questions from lecture materials, including multiple choice, true/false, matching, and fill-in-the-blank questions

d. Simulation Features

• Software for teaching and simulating fundamental principles in Power Electronics through animations and interactive simulations
• Includes detailed theoretical content covering both basic and advanced principles
• Theory and simulation of electronic and power electronic components and devices: insulation, semiconductors, diodes, transistors, and power electronic devices
• Simulation of triggering and switching methods:
  • Thyristor turn-on/turn-off methods
  • Gate triggering methods
• Simulation of gate trigger circuits:
  • General trigger circuits
  • Resistance trigger circuits
  • Half-wave and full-wave resistance trigger circuits
  • UJT oscillator
  • Synchronized UJT triggering
  • Ramp triggering methods
• Simulation of phase-controlled rectifiers
• Simulation of chopper circuits:
  • DC-DC choppers
  • Buck converters
  • Boost converters
  • AC choppers
  • Related applications
• Simulation of direct inverters:
  • Triggering diagrams
  • Single-phase direct inverters and applications
• Simulation of AC voltage controllers
